Glassworker (Glass Lifter) 625kg
- Model
- GW625
- Made in
- Germany
UPLIFTER is a company headquartered in Germany, an international market leader in the field of lifting and vacuum technology with a comprehensive product range including glass lifters, material handling machines, etc… After more than 20 years of development, Uplifter now has branches throughout Germany and other European and Asian countries…
This equipment has many different models,
for more details please contact us.
Overview
- Glassworker GW625 is suitable for common uses in various environments such as apartments, stores, buildings, shophouses, etc.
- It’s perfect for construction projects with large glass panels or facade components requiring a load capacity of up to 625 kg.
- It can unload, transport, and install glass and metal sheets on uneven ground.
- With a width of only 0.83 m, GW625 is also suitable for narrow workspaces in hallways and doorways. The machine can perform vertical installations up to 3.10 m and reach up to 3.60 m.
- The continuously variable drive is perfectly coordinated with three-dimensional control technology, customizable vacuum system, and standard wireless remote control. With optimal pulling force, GW625 is also suitable for outdoor use.
- Prevents breakage during glass installation and doubles safety. It is fully capable of safely transporting and assembling glass with just one worker.
- Silicone-free suction plates (no marks)
- Fully hydraulic extension and ensitive hydraulics
- Sensitive radio remote control with LCD display, charger, second battery and accessories
- Self-monitoring safety system – Visual display of all queries in the radio remote control
- Plug & play delivery, overload key, automatic angle correction, hydraulic turning and hydraulic swivelling
- Operating instructions with CE declaration of conformity
Recognizing the benefits of this equipment, NISHIO has partnered with Uplifter and directly imported the Glassworker model GW625 for Vietnamese customers to experience and check the quality of the machine.
Load capacity max.
625 kg
Working height
3.646 m Centre vacuum cross
Overhead mounting
4.10m
Additional manual extension
610 mm
Hydraulic side shift in vacuum cross
+/- 50 mm
6 suction plates
Ø 350 mm
Front drive
3 kW
Own weight
1035 – 1095 kg
